High Speed Powder Packing Machine JT-320

Application：

Suitable for packaging many different kinds of products；such as coffee powder, milk, vitamin powder, and etc.

Technical Features：

1. PLC control with stable reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing, cutting, and finished in one operation.
2. Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable.
3. Film-pulling with servo motor double belt: less pulling resistance, bag is formed in good shape with better appearance; belt is resistant to be worn-out.
4. External film releasing mechanism: simpler and easier installation of packing film.
5. Adjustment of bag deviation just needed to be controlled by the touch screen. Operation is very simple.
6. Close down type mechanism, defending powder into inside of machine.

Specifications：

Type         JT-320
Bag length 50-200mm(L)
Bag width 40-150mm(W)
Max width of roll film 320mm
Packing speed 10-100bags/min
Type of sealing Pillow bag or 3-side sealing
Air consumption 0.65mpa
Gas consumption 0.25m3/min
Power voltage 220VAC/50Hz/ 60Hz
Power 2 KW
Dimension 1200mm(L)*700mm(W) *1520mm (H)
Weight 400 kg
Inquire for sizing options
